Tenda SG110PC PoE Switch

Description

🔌 Compact Unmanaged PoE Switch for Small Networks

The Tenda SG110PC is a 10-port Gigabit unmanaged PoE switch designed for plug-and-play deployment in small office, retail, and surveillance environments. With 8 PoE-enabled ports and 2 uplink ports, it delivers both data and power over Ethernet, simplifying device connectivity without the need for complex configuration. Its compact form factor and wall/desktop mounting options make it ideal for space-constrained setups.

⚙️ Hardware and Interface Overview

• Dimensions: 175 × 127 × 43 mm
• Mounting: Desktop and wall (rack not supported)
• Enclosure Material: Metal
• Interfaces:
  • 8 × 10/100/1000 Base-TX (Data/Power)
  • 2 × 10/100/1000 Base-TX (Data only)
• LED Indicators:
  • 10 × Link/Act
  • 1 × Power
• Transmission Media: CAT5/5e UTP or better
• Input Voltage: 190–240V AC, 50/60Hz
• Level of Protection: 4KV surge

Built for simplicity and durability, the SG110PC offers essential connectivity with minimal setup.

📡 Network Performance and PoE Capabilities

• Switching Capacity: 20Gbps
• Forwarding Rate: 14.9 Mpps
• MAC Address Table: 4K entries
• Forwarding Mode: Store-and-forward
• PoE Budget:
  • IEEE802.3af/at compatible
  • Total power: 100W
  • Max per port: 30W

This switch supports a variety of PoE devices including IP cameras, wireless APs, and VoIP phones, making it a versatile choice for small-scale deployments.

🌡️ Environmental Resilience

• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 70°C
• Operating Humidity: 10%–90% RH (non-condensing)
• Storage Humidity: 5%–90% RH (non-condensing)

Engineered for indoor use, the SG110PC maintains stable performance in typical office and retail environments.

🎯 Ideal for Plug-and-Play Network Expansion

The Tenda SG110PC is perfect for users who need reliable PoE switching without the complexity of managed configurations. Its 100W power budget, gigabit speeds, and compact design make it a practical solution for expanding small networks quickly and efficiently. Whether you’re powering a few cameras or connecting access points, this switch delivers dependable performance with zero fuss.
