-Wireless: 1167Mbps
-Interface: 10/100/1000 Mbps Ethernet Port (PoE)
-Antenna: 2*5dBi, RP-SMA Connector (detachable)
-Frequency: 2.4 GHz & 5 GHz
-Working Modes: AP, Client+AP
-Transmission Range: 200m
-Power: 802.3af & 24V 0.5A Passive PoE
| Model | OAP1200 |
| Category | Outdoor AP |
| Dimension | 194.7*83*42.1 mm |
| Interface | One 10/100/1000 Mbps Ethernet Port (PoE) |
| Button | 1*Reset |
| LED indicator | 1 x SYS |
| Maximum Power Consumption | 11.5w |
| Power Supply | 802.3af & 24V 0.5A Passive PoE |
| Max. Number of Clients | 256 |
| Recommended Clients | 38 |
| Antenna | 2.4GHz: 2 x 4dBi |
| 5GHz: 2 x 4dBi | |
| 2.4GHz maximum power | 23+/-1.5dBm |
| 5GHz maximum power | 23+/-1.5dBm |
| Reception Sensitivity | 802.11b -93 dBm |
| 2.4 GHz 802.11n (MCS7) -73dBm | |
| 5 GHz 802.11a -93 dBm | |
| 5 GHz 802.11n (MCS7) -74 dBm | |
| Frequency Range | 2.4GHz&5GHz |
| Standard&Protocol | 802.11a/b/g/n/ac(wave2) |
| Maximum wireless speed | 2.4GHz: 300Mbps |
| 5GHz: 867Mbps | |
| Bandwidth | 20MHz/40MHz/80MHz |
| Operating Mode | AP/Client+AP |
| Max. No. of SSID | 2.4GHz: 8 |
| 5GHz: 4 | |
| Hide SSID | Supported |
| OFDMA | Supported |
| Beamforming | Supported |
| Fast roaming（802.11k/v/r） | Supported |
| WEP | Supported |
| WPA-PSK | Supported |
| WPA2-PSK | Supported |
| WPA | Supported |
| WPA2 | Supported |
| Access control | Supported |
| Adjustable power transmit | Supported |
| Automatic channel | Supported |
| AP isolation | Supported |
| Guest network | Supported |
| Connected clients control | Supported |
| RSSI Threshold | Supported |
| Weak signal terminal elimination | Supported |
| Prioritize 5 GHz | Supported |
| VLAN tagging for SSID | Supported |
| LED control | Supported |
| MU-MIMO | Supported |
| Diagnostics tool | Supported |
| Reboot at specified interval | Supported |
| Scheduled reboot | Supported |
| Device management | Web management |
| Router management | |
| System logs | Supported |
| Firmware upgrade | Supported |
| Reboot | Supported |
| Reset | Supported |
| Backup configuration | Supported |
| Restore configuration | Supported |
| Default IP | 192.168.0.254 |
| Default username | admin |
| Default password | admin |
| Operation Temperature | -30℃ ~ 50℃ |
| Operating Humidity | 10%~90% non-condensing |
| Storage Temperature | -30℃ ~ 70℃ |
| Storage Humidity | 10%~90% non-condensing |
| Categories | Access Point |
|---|---|
| Brand |
